Appearance size diagram

Type and technical parameters:

Type		T/T1	Export number (N)	Export caliber	A	B	Weight (g)
DE04104	30202	Ø 4 Ø 4	4	Ø 4	48	36	70
DE04204		Ø 6 Ø 4		Ø 4
DE04304		Ø 6 Ø 6		Ø 4
DE04306		Ø 6 Ø 6		Ø 6
DE06104		Ø 4 Ø 4	6	Ø 4	64	52	92
DE06204		Ø 6 Ø 4		Ø 4
DE06304		Ø 6 Ø 6		Ø 4
DE06306		Ø 6 Ø 6		Ø 6
DE08104		Ø 4 Ø 4	8	Ø 4	80	68	116
DE08204		Ø 6 Ø 4		Ø 4
DE08304		Ø 6 Ø 6		Ø 4
DE08306		Ø 6 Ø 6		Ø 6
DE10104		Ø 4 Ø 4	10	Ø 4	96	84	138
DE10204		Ø 6 Ø 4		Ø 4
DE10304		Ø 6 Ø 6		Ø 4
DE10306		Ø 6 Ø 6		Ø 6
DE12104		Ø 4 Ø 4	12	Ø 4	112	99	159
DE12204		Ø 6 Ø 4		Ø 4
DE12304		Ø 6 Ø 6		Ø 4
DE12306		Ø 6 Ø 6		Ø 6

Note:
1. Ø 4 interface thread is M8x1.0; Ø 6 interface thread is M10x1.0; other special products can be customized;
2. DE (Group) is organized with casing and casing cap: the only dispenser (only) is organized.
